Outdoor Lighting
Square and parks
Private Gardens
City roads
Civil or Government road project
|
Model |
Power |
LED |
LED QTY |
Total Flux |
Surge |
Product size (mm) |
Packing Size (mm) |
|
ASNB-40W-05 |
40W |
Lumileds3030 |
40PCS |
4000lm |
2KV |
410*100*75 |
485*240*120 |
|
ASNB-60W-05 |
60W |
Lumileds3030 |
60PCS |
6000lm |
4KV |
550*235*120 |
530*240*120 |
|
ASNB-100W-05 |
100W |
Lumileds3030 |
100PCS |
10000lm |
4KV |
550*235*120 |
620*290*150 |
|
ASNB-150W-05 |
150W |
Lumileds3030 |
150PCS |
15000lm |
4KV |
675*275*120 |
740*340*150 |
|
ASNB-200W-05 |
200W |
Lumileds3030 |
200PCS |
20000lm |
4KV |
720*275*120 |
790*340*150 |
◆ Material: Aluminum with optical lens
◆ Finishing: Surface anti-ageing electrostatic spray processing, super resistance to corrosion.
◆ Driver: Isolated
◆ Input voltage: AC85~265V/50-60Hz
◆ Beam angle: 150 ̊*80 ̊
◆ Efficiency: >100lm/W
◆ IP grade: 65
◆ CCT: 2700K~6500K
◆ PF: >0.95
◆ CRI: >70/80
◆ Warranty: 3 or 5 years for option
◆ Photo sensor: For option
1. Opening a street light housing Mould
2. Support SKD/CKD according to customer housing
3. Offer housing only
